AI-Thinker GP-02 GPS Module – High Precision Satellite Positioning Module
Product Description
The AI-Thinker GP-02 GPS Module is a compact and high-performance positioning module designed for navigation, tracking, robotics, drones, and IoT applications. It provides accurate real-time location, speed, altitude, and timing information by receiving signals from GPS satellites.
With fast satellite acquisition, low power consumption, and a simple UART interface, the GP-02 module can be easily integrated with microcontrollers such as Arduino, ESP32, STM32, and Raspberry Pi. Its reliable performance makes it an excellent choice for location-based projects and embedded navigation systems.
Key Features
✔ High-Precision GPS Positioning
✔ Fast Satellite Acquisition & Tracking
✔ Real-Time Location and Navigation Data
✔ UART Serial Communication Interface
✔ Low Power Consumption
✔ Compact and Lightweight Design
✔ Built-in Ceramic Antenna
✔ Supports NMEA Standard Protocol
✔ Easy Integration with Popular Development Boards
✔ Stable Performance in Outdoor Environments
✔ Reliable Navigation and Tracking Capability
✔ Suitable for Embedded GPS Applications
Technical Specifications
| Parameter | Specification |
|---|---|
| Module Model | AI-Thinker GP-02 |
| Positioning System | GPS |
| Communication Interface | UART Serial |
| Protocol | NMEA 0183 |
| Operating Voltage | 3.3V – 5V |
| Antenna Type | Built-in Ceramic Antenna |
| Update Rate | Up to 10Hz |
| Position Accuracy | Up to 2.5m CEP (Typical) |
| Cold Start Time | < 35 Seconds |
| Hot Start Time | < 1 Second |
| Operating Temperature | -40°C to +85°C |
| Dimensions | Compact GPS Module Form Factor |
Package Includes
✔ 1 × AI-Thinker GP-02 GPS Module
Important Information
- GPS modules require outdoor access or clear sky visibility for optimal satellite reception.
- Initial satellite lock may take several minutes depending on environmental conditions.
- Compatible with Arduino, ESP32, STM32, Raspberry Pi, and other microcontroller platforms.
- Product images are for illustration purposes only. Actual product may vary slightly depending on manufacturer revisions.
