Description
The MARK5 5-Inch 225mm FPV Carbon Fiber Frame (Blue Edition) is a premium, high-durability freestyle platform engineered to balance extreme structural stiffness with advanced electronics protection. Featuring CNC-machined 7075 aluminum alloy side plates in a striking blue finish, it provides superior, rugged defense for your FPV camera lens. Its specialized shock-absorbing Wide-X arm geometry delivers a rock-solid, ultra-flexible flight attitude while keeping mid-air vibrations away from your gyro. Highly versatile and easy to assemble, this frame comes fully equipped with dedicated TPU mounts for action cameras like the GoPro 8, and native mounting holes for clean integration with DJI Air Unit, Vista, or standard analog video transmitters.
Technical Specifications
| Specification | Details |
| Model | MARK5 5-Inch Blue |
| Frame Type | 5-Inch FPV Freestyle / Racing Frame Kit |
| Frame Wheelbase | 225 mm |
| Frame Geometry | Wide-X Layout |
| Material Construction | Premium Carbon Fiber + 7075 Aluminum Alloy + TPU |
| Arm Thickness | 5.0 mm |
| Body Plate Thickness | 2.5 mm / 2.0 mm |
| Compatible Propeller Size | 5 Inches |
| Flight Controller Mounting | 30.5 x 30.5 mm |
| VTX Mounting Patterns | 30.5 x 30.5 mm / 20 x 20 mm |
| Motor Mounting Holes | 16 x 16 mm / 19 x 19 mm |
| Camera Lens Compatibility | 19 mm to 20 mm Width (Direct support for DJI lenses) |
| Weight | ~210 grams |
Package Includes
-
1 x MARK5 5-Inch 225mm Carbon Fiber Frame Kit
-
2 x 7075 Aluminum Alloy Camera Side Plates (Blue)
-
4 x 5mm Carbon Fiber Frame Arms
-
1 x Complete Set of Top, Mid, and Bottom Plates
-
1 x Blue TPU Hardware Pack (GoPro Base, Antenna Mounts)
-
1 x Assembly Screw and Standoff Hardware PackNote: Product images are shown for illustrative purposes only. This package includes the bare carbon fiber frame, aluminum side plates, and TPU parts; all flight electronics, motors, ESCs, camera modules, and propellers must be purchased separately.
